WhisperKool SS12000 Wine Cellar Cooling System

WhisperKool SS12000 Wine Cellar Cooling System

(0 reviews)
SKU#: SS120

The Quantum Series cooling units are our newest, most advanced cooling systems.  This fully ducted split system comes in one size, 12000 BTUs. Utilizing 404A refrigerant, this system has the built in capacity to be installed outside in cold weather climates where temperatures get as low as -15 degrees.  Simple to install by a certified technician, our pump down technology does not require any wiring from the condenser to the evaporator.  Featuring interchangeable panels which allow the installer to direct the air flow in the most efficient direction to maintain maximum efficiency.

Product Features: Fully Ducted Spilt System 12000 BTU capacity for larger cellars Interchangeable evaporator airflow panels Pump down system technology Advanced electronic displaywhisperkool video icon Liquid bottle probewhisperkool video icon Energy saving mode Cold weather climates to -15 degrees Fahrenheit Electro-fin coated coils for protection against outgassing that occurs in cellars Condensing unit can be placed outdoors w/optional housing Designed with the highest quality, professional grade parts for longevity and performance Durable galvanized housing 50ft Control & Liquid Bottle Probe 2 year warranty Specifications: Cellar Size: 4,000 cu. ft. (Each wine cellar is unique and has speci c cooling requirements . Heat load calculations should always be performed prior to selecting a cooling unit.) BTUh @ 85F°: 12530 CFM: 810 Dimensions (Condensing Unit): Evaporator: 29.5”L x 30.9”W x 19.8”H Condenser: 24”L x 19.4”W x 16.1”H Refrigerant: R-404a HP: 1 1/4 Voltage Rating: Evaporator: 115V (20 amp Dedicated Curcuit Required) Condenser: 230V (20 amp Dedicated Curcuit Required) Weight: Evaporator: 96 lbs Condenser: 95 lbs AMPS (starting/running): Evaporator: 4.3/3.2 Condenser: 39.6/9.9 Line Set: 1/4” Liquid Line Suction Line (Less than 25ft - 5/8” ) (Greater than 25ft - 7/8”) Drainline: 3/4” CPVC Installation: Evaporator can be installed up to 25 duct feet away from cellar with 14” flex duct Thermostat: Remote display with 50-ft. cable Temp. Delta: 55°F temperature differential between the cellar temperature and condenser air intake temperature. Warranty: limited 2 year parts and labor

Manufacturer: WhisperKOOL

Specs/Warranty: Manufacturer's WarrantyA limited 2-year/5-year compressor warranty is offered with all self-contained cooling units at their date of purchase. A limited 2-year warranty is offered with all split systems. This warranty does not start or become valid

Manufacturer Part Number: SS12000

Custom Stock Status: Made to Order
